Compact light-weight 10 m (32 ft) mast

$83.07
(Inc. Tax)
$69.22
(Ex. Tax)

NOTE Customers outside the Eu pay the lower (Ex. Tax) prices!

(53 reviews) Write a Review
SKU:
CLWM-100
Availability:
This mast ships Worldwide
Shipping:
Calculated at Checkout

 The Travel Mast: a compact lightweight telescopic mast


***IMPORTANT NOTE: IF USING THIS MAST WITH A BAND HOPPER ANTENNA WE RECOMMEND ATTACHING THE ANTENNA NO HIGHER THAN 6 METRES (20FT) UP THE MAST (top of section 11 - counted from base/outer section)***

This is our 10m (33ft) Travel Mast. With a transport-length of only 67cm ( 26.5 inches ) it fits in a suitcase making it perfect for vacation DXing.

Detailed Specifications:

Not sure which mast to choose? Click here for our handy comparison chart.

Extended length: 10 metres (32 ft). Lengths approximate - click here to find out more.

Packed length: 67 cm (26.4 inches)

Number of sections: 17

Wall thickness: 1.5 mm (0.06 inches) bottom, 0.67 mm (0.03 inches) top

Weight: 1.3 kg (2.9 lbs)

Mast Material: glass-fiber composite (non-conducting)

Tube diameter: top 3.9mm (0.15 inches) base 49 mm (1.9 inches)

Base cap diameter: 55 mm (2.2 inches)

Tube colour: Light grey

Mast sections hollow to the top

Supplied with black carry bag with tie

FAQ:

Spare parts are available - see below.

The mast is made of Glass Reinforced Plastic (GRP) = Fiberglass. This is an insulator with excellent RF properties (very low loss).

Friction lock: pull each section firmly with a twisting motion for best lock. When erecting always start with the smallest section. When taking down always start with the largest section.

Top sections may be removed by unscrewing the endcap at the bottom of the mast.

Spare parts:

A benefit of this premium product is our spares support.

The following spares are available for the 10m Compact Travel Mast:

Instructions are available HERE!

Also available from our international agent(s):

dx-engineering-reseller.pnghambuy-reseller-logo-2-.jpgchristech-reseller2.jpgtacticom-reseller-3-.png





 All dimensions approximate.

53 Reviews Hide Reviews Show Reviews

  • 5
    Great gear!!!

    Posted by N5EIT on 3rd Jul 2019

    I use this with the drive on mast stand and it works a charm. Recently set up with this and a log on the drive on stand just outside my tent so I could be in comfort while operating. It was a sweet setup. I also carry it on my bike rack when bicycle touring for any radio ops that I can do. Nice gear!!!

  • 4
    SO TAke one!

    Posted by John ( aka Jack ) Moxness on 16th Jun 2019

    Right product for me as I plan to travel internationally with this. Using it with an LNR 10/20/40 MK II end-fed. Gets it up as a sloper to multiple heights very rapidly. Recommended for portable all over operation. 73 de VA6JDM

  • 5
    compact light weight 10m mast

    Posted by wayne on 13th Jun 2019

    Very useful tool, fitted in suitcase for a recent flight. easily deployed. I have made a 3 wire guy point for it at about 2.5 metres up and use the band hopper dipole as just 2 sloping drops so that the pole isn't flexing around under a 3 drop arrangement at the top.

  • 5
    Nice Portable Mast

    Posted by Chris on 16th May 2019

    I purchased this mast due to it's short packed length and it's relative light weight. I hope to make a lot of SOTA contacts using this mast to raise my antenna.

    I will pass on a tip I read somewhere, cut up an old mousepad and put a piece under the mast sections on the bottom so if it falls the blow is softened. It helped me out one time when I apparently didn't lock the sections solidly, once the first section fell, the remaining sections collapsed in sequence and I had no damage due to the mousepad.

  • 4
    Decent Mast

    Posted by Brian Perry on 10th Mar 2019

    I use this mast with the Sotabeam 4-band. I had never used a mast of this sort before and after several failed attempts to keep the smaller ends from falling out (I opened the wrong end) it deploys quite easily. A small twist for each section keeps the section in place. I have used twice thus far and it has withstood the winds of a large thunderstorm. Fairly light weight and easy to carry, but slightly too long for backpacking unless attached to the bottom of the pack. I will use as an emergency mast when on the road traveling in the United States for my work.

  • 5
    Great light weight mast

    Posted by John Sager on 7th Sep 2018

    This mast is a great piece of kit for portable operations. I have a heavier mast for my car trips but this mast works great for backpack or suitcase trips. Highly recommended!

  • 5
    Excellent

    Posted by Alan on 11th Jul 2018

    Very good mast

  • 5
    Light-weight yet sturdy

    Posted by Linas Balsys LY2H on 24th Jun 2018

    I was pleasantly surprised when unpacked the parcell by really compact size of this 10m mast with only 68cm collapsed. I thought it might be a bit too much like a flimsy "fishing device" but it was not! I found it thick enough at the 8m level in order to support my lightweight doublet ( 30m long with 10m home made open air feeder). Erection is easy, the mast stood for couple of hours self supporting with no need of counterropes nor tape-reinforcement of the section joints. Taking down is equally quick and easy. Besides using this pole for my doublet support I also use it as a 10m vertical in variuos configurations for the qrp field work. Being such a short collapsed and lightweight it is my Nr1 choise for the short bycicle-portable trips to activate Hillfort and Flora-Fauna sites of local award programmes. The only minor remark - the bottom cap of the pole makes the bottom end 1cm thicker than the first bottom segment which is 5cm. This makes a bit of inconvienience when binding the pole to the support structures or inserting it into the supporting tube of the mast holder. But on the other hand thicker bottom makes it more solid to stand on and protects the other sections from damage in the event of uncontrolled collapse. In this context it is a good advise to put some packing fome taken from the packing of the parcell into the space under the bottom cap.

  • 5
    Very Light and compact

    Posted by Neil M0NJH on 12th Jun 2018

    Top sections above 7m easily removed as Richard suggests if not required for bandhopper. Taken abroad in hand luggage through airport security with no problems. Does require a little packing inside the base to cushion the poles when folding down and stop them rattling around- a handful of bubble wrap does the trick.
